| 적용압축기 Application for compressor |
냉각탑형식 FCT Models |
냉각열량 Cooling Capacity |
표준수량 Water Vol |
팬동력 Fan Motor |
접속구경 Conn. Size |
외형치수 Dimension |
중량 Weight |
|---|---|---|---|---|---|---|---|
| kcal/hr | ℓ/min | kW | inch | LxWxH | Kg | ||
| AS51 | CT-F10PF1 | 39,000 | 130 | 0.2 | 1 1/2 | 1180x960x1780 | 70 |
| AS76 | CT-F15PF1 | 58,500 | 195 | 0.4 | 2 | 1080x960x1170 | 80 |
| AS101 | CT-F20PF1 | 78,000 | 260 | 0.4 | 2 | 1150x1030x1895 | 88 |
| AS151 | CT-F30PF1 | 117,000 | 390 | 0.75 | 2 1/2 | 1390x1250x2120 | 124 |
| AS201 | CT-F40PF1 | 156,000 | 520 | 0.75 | 3 | 1715x1550x2315 | 200 |
| AS301 | CT-F60PF1 | 234,000 | 780 | 1.5 | 3 | 1910x1750x2585 | 250 |
| AS401 | CT-F80PF1 | 312,000 | 1040 | 2.2 | 4 | 2100x1980x3120 | 340 |
| AS501 | CT-F100PF1 | 390,000 | 1300 | 2.2 | 4 | 2580x2460x3340 | 585 |
