| Compressor Type |
Max.Working Pressure | Capacity | Motor Power | Noise | Dimension(LxWxH) | Air Outlet | Weight | |||
|---|---|---|---|---|---|---|---|---|---|---|
| barg | psig | LPM | CFM | kw | HP | dB(A) | mm | A(B) | kg | |
| AL3 | 8.0 9.9 |
113.7 140.8 |
271 219 |
9.6 7.7 |
2.2 | 3 | 50 | 650x735x1140 | 15(1/2) | 191 |
| AL5 | 8.0 9.9 |
113.7 140.8 |
420 352 |
14.8 12.4 |
3.7 | 5 | 50 | 650x735x1140 | 15(1/2) | 209 |
| AL7 | 8.0 9.9 |
113.7 140.8 |
691 571 |
24.4 20.2 |
2.2x1 3.7x1 |
3x1 5x1 |
52 | 640x1180x1050 | 25(1) | 334 |
| AL10 | 8.0 9.9 |
113.7 140.8 |
840 704 |
29.6 24.9 |
3.7x2 | 5x2 | 53 | 640x1180x1050 | 25(1) | 340 |
| AL15 | 8.0 9.9 |
113.7 140.8 |
1260 1056 |
44.4 37.3 |
3.7x3 | 5x3 | 56 | 710x1140x1245 | 25(1) | 455 |
| AL20 | 8.0 9.9 |
113.7 140.8 |
1664 1408 |
59.2 49.7 |
3.7x4 | 5x4 | 58 | 710x1140x1610 | 25(1) | 580 |
| AL25 | 8.0 9.9 |
113.7 140.8 |
2100 1760 |
74.0 62.2 |
3.7x5 | 5x5 | 59 | 710x1140x1975 | 25(1) | 700 |
| AL30 | 8.0 9.9 |
113.7 140.8 |
2520 2112 |
88.8 74.6 |
3.7x6 | 5x6 | 62 | 1600x1215x1245 | 40(1 1/2) | 860 |
| AL40 | 8.0 9.9 |
113.7 140.8 |
3360 2816 |
118.4 99.4 |
3.7x8 | 5x8 | 63 | 1600x1215x1610 | 40(1 1/2) | 1150 |
| AL50 | 8.0 9.9 |
113.7 140.8 |
4200 3520 |
148.0 124.3 |
3.7x10 | 5x10 | 65 | 1600x1215x1975 | 40(1 1/2) | 1360 |
| AL60 | 8.0 9.9 |
113.7 140.8 |
5040 4224 |
178.0 149.0 |
3.7x12 | 5x12 | 88 | 1600x1280x2405 | 40(1 1/2) | 1900 |
- 규격 및 사양은 제품의 개량 등으로 사전예고 없이 변경될 수 있습니다.
