Compressor Type |
Max.Working Pressure | Capacity | Motor Power | Noise | Dimension(LxWxH) | Weight | Air Outlet | |||
---|---|---|---|---|---|---|---|---|---|---|
barg | psig | ㎥/min | cfm | kw | HP | dB(A) | mm | kg | A(B) | |
ASM20B | 7.0 8.5 9.5 |
100 120 135 |
2.6 2.2 2.1 |
91.3 77.3 73.8 |
15 | 20 | 70 | 1400x830x1350 | 480 | 25(1) |
ASM30T | 7.0 8.5 9.5 |
100 120 135 |
3.70 3.50 3.30 |
130 130 106 |
22 | 30 | 63 | 1400x830x1350 | 757 | 25(1) |
ASM50 | 7.0 8.5 9.5 |
100 120 135 |
6.80 5.80 5.30 |
205 205 187 |
37 | 50 | 65 | 1660x1030x1607 | 1140 | 40(1 1/2) |
ASM75 | 7.0 8.5 9.5 |
100 120 135 |
10.20 9.20 8.30 |
360 360 293 |
55 | 75 | 72 | 2000X1210X1857 | 1780 | 50(2) |
ASM100 | 7.0 8.5 9.5 |
100 120 135 |
12.30 12.10 11.10 |
432 432 363 |
75 | 100 | 75 | 2000X1210X1857 | 1780 | 50(2) |
ASM150 | 7.0 8.5 9.5 |
100 120 135 |
21.00 19.00 16.30 |
750 724 586 |
110 | 150 | 78 | 2550x1470x2156 | 2785 | 65(2 1/2) |
ASM200 | 7.0 8.5 9.5 |
100 120 135 |
25.10 25.00 24.00 |
860 843 825 |
160 | 215 | 79 | 2700x1640x2156 | 3000 | 80(3) |
ASM250 | 7.0 8.5 9.5 |
100 120 135 |
30.30 30.10 27.00 |
1024 1024 925 |
190 | 250 | 81 | 2700x1640x2156 | 3250 | 80(3) |
ASM300 | 7.0 8.5 9.5 |
100 120 135 |
42.80 38.00 37.00 |
1420 1284 1247 |
225 | 300 | 84 | 4080x1900x2356 | 6200 | 100(4) |
ASM350 | 7.0 8.5 9.5 |
100 120 135 |
45.00 42.00 41.50 |
1682 1543 1462 |
265 | 350 | 87 | 4080x1900x2356 | 6350 | 100(4) |
ASM400 | 7.0 8.5 9.5 |
100 120 135 |
53.67 49.12 48.39 |
1889 1729 1703 |
300 | 400 | 89 | 4080x1900x2356 | 6430 | 100(4) |
Compressor Type |
Max.Working Pressure | Capacity | Motor Power | Noise | Dimension(LxWxH) | Weight | Air Outlet | |||
---|---|---|---|---|---|---|---|---|---|---|
barg | psig | ㎥/min | cfm | kw | HP | dB(A) | mm | kg | A(B) | |
ASM120 | 8.5 9.5 |
100 135 |
12.4 12.5 |
437.9 434.3 |
75 | 100 | 75 | 2000X1210X1857 | 1750 | 50(2) |
ASM230 | 7.0 8.5 |
100 135 |
26.4 25.6 |
903 899 |
160 | 215 | 79 | 2700X1640X2156 | 3980 | 80(3) |
